VIVIO GP1705-2G
The BDCOM GP1705-2G Series is a smart xPON Multi-service Broadband Access Home Gateway Unit (HGU) designed for integrated multi-service networks in telecom operator deployments. Compliant with international standards ITU-T G.984/G.988 and IEEE 802.3ah, PRC Communication Industry Standards GB/T33845-2017 and YD/T 1475-2006, as well as China Telecom EPON/GPON Technical Requirements (CTC), the GP1705-2G series offers seamless interoperability with mainstream OLT vendors to minimize infrastructure rollout costs. The device features automatic switching between EPON and GPON networks, dual-band 1200Mbps Wi-Fi 5 wireless connectivity, robust service security, and comprehensive OMCI/OAM management capabilities to deliver high-quality broadband and data services to residential and small office environments.
• 1 x SC/UPC xPON port (GPON/EPON auto-adaptive)
• 2 x Gigabit Ethernet (GE TX) RJ45 UNI ports
• 1 x USB port
• Dual-band 1200Mbps Wi-Fi 5 (802.11a/b/g/n/ac) with 4 external antennas (2x2 MIMO)
• GPON transmission rate: Downlink 2.5 Gbps / Uplink 1.25 Gbps (1:128 split ratio)
• EPON transmission rate: Downlink 1.25 Gbps / Uplink 1.25 Gbps (1:64 split ratio)
• Advanced VLAN capabilities: 4K VLAN, port-based, IEEE 802.1Q, tag/transparent/aggregation/trunk/translation mode, CTC2.0
• QoS & Traffic Control: Backpressure flow control, IEEE 802.3x flow control, 4 priority queues per port, WR/SP/FIFO scheduling, SLA, and DBA
• Multicast support: IGMP snooping, MLD snooping, CTC defined dynamic multicast, multicast group limitation, fast-leave
• Security: MAC address number limit, MAC filtering, port protection, AES-128 encryption, MAC/Loid/Hybrid authentication
• Management & Diagnostics: CLI, HTTP, SNMP, TR069, TELNET, OMCI, OAM, loop detection, Dying-Gasp, TX/RX optical power alarms
About ONU
ONU: device in an FTTx network connecting subscriber equipment to the optical network for internet, TV, and phone services.
