Optowire Anchor clamp PA-39
Anchoring clamps PA-39 for ADSS cables round fiber optic cables installed on short spans (100 m max) is made of one opened conical fiberglass reinforced body, a pair of plastic wedges, and a flexible bail, fire-resistant plastic and fire-resistant spray coating used to support and secure thinner liners. This flexibility enables us to propose optimized and tailor-made clamp design depending on the ADSS cable constructions.
● Cable diameter(mm) - 5-9
● Material: high strength UV resistant polymer
● Operating temperature, °C: -40 to 50
● Allowable load(KN): 3
About Anchor Clamp
Anchor clamps secure ADSS, FIG-8, Drop cables on poles and walls. UV-resistant, corrosion-proof, for round or flat cables. Easy, tool-free installation.
