Optowire OM3, MTP(UPC)-LC(UPC) Trunk Cable 144 (12x12) Core, 2,0mm, LSZH, 10m.
The Optowire OM3 MTP(UPC)–LC(UPC) Duplex Type B Trunk Cable (144FO, 12×12, 10m) is an ultra high-density optical connectivity solution designed for large-scale data center and backbone infrastructures. Featuring twelve 12-fiber MTP connectors, it enables efficient aggregation of LC duplex channels, maximizing rack space and simplifying cable management in high-density environments. With low insertion loss and high return loss performance (MTP ≥ 20 dB, LC ≥ 50 dB), it ensures stable high-speed transmission with minimal signal reflection. The LSZH outer sheath enhances fire safety, while bend-insensitive OM3 fiber provides flexibility and long-term durability. Ideal for scalable 40G/100G network deployment and future expansion.
- OM3 multimode MTP(UPC) to LC(UPC) duplex trunk cable
- 144-core (12×12) ultra high-density configuration with Type B polarity
- Low insertion loss: MTP ≤ 0.35 dB, LC ≤ 0.3 dB
- Return loss: MTP ≥ 20 dB, LC ≥ 50 dB
- LSZH 2.0 mm jacket, flame-retardant and halogen-free
- Designed for hyperscale 40G/100G data center networks
About Multi-Mode
Multi-mode patch cords are ideal for short-distance data links, offering fast, low-loss connections between switches, servers, and network panels.
