OM3-ID-OR-16FO-Aqua Multimode Indoor Optical Cable
Article:T-OC-MMC-IMMC-0003
Category:Indoor MM Cable
Brand: Optowire
Unit:m
The OptoWire OM3-ID-OR-16FO-Aqua is a high-density indoor optical cable designed for data centers, LAN backbones, and communication networks. It features sixteen OM3 multimode fibers arranged around a central FRP strength member, reinforced with glass yarns for enhanced durability and flexibility. The tight-buffered design ensures easy termination, while the LSZH aqua jacket offers superior flame retardancy, low smoke emission, and compliance with IEC 60332 standards. Compact, lightweight, and reliable, this cable guarantees stable optical performance and long-term reliability in structured indoor cabling systems.
- Multimode indoor optical cable, OM3 50/125 µm
- Fiber count: 16 cores, tight-buffered LSZH construction
- Central FRP strength member reinforced with glass yarns
- Aqua LSZH outer sheath, flame-retardant and halogen-free
- Outer diameter: 7.3 ± 0.5 mm
- Tensile strength: 700 N (installation), 200 N (operation
