Cable Cross-Section CSC-24FO-0.6kN
The Optowire CSC-24FO-0.6kN cross-section cable is designed for high-density indoor fiber installations in data centers and backbone environments. It features 24 G.652D fibers with tight-buffered construction, aramid yarn reinforcement, and a central dielectric strength member for excellent mechanical stability. The LSZH outer jacket ensures flame retardancy and low smoke emission, making it ideal for safe indoor environments. With high tensile strength (600 N) and crush resistance (1000 N/100 mm), this cable guarantees long-term durability and performance for structured cabling systems.
- Indoor optical cable with 24 fibers (G.652D type)
- Tight-buffered LSZH design with aramid yarn strength member
- Central non-metallic strength element and LSZH outer jacket
- High tensile and crush resistance for secure installation
- Flame-retardant, low-smoke jacket suitable for data centers
- Compact structure for easy routing and termination
About Cross Section Cable
High-density LSZH optical cross-section cables engineered for data centers, offering flame resistance, flexibility, and superior performance in structured networks.
